CL11 Polyester Film Capacitor

Name: CL11 Polyester Film Capacitor
Brand: GDHY
Price: 0.03 USD

China CL11 Polyester Film Capacitor wholesale

Brand Name : GDHY

Model Number : CL11 2J103

MOQ : 50Kpcs

Price : USD0.03/PC

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 1KKpcs/Month

Delivery Time : 14days

Certification : SGS,ISO

Place of Origin : CHINA

Capacity : 0.01uF

Voltage : 630VDC

Size : 11mm*13mm*6.5mm

Pitch : 7.5mm

Model : CL11 2J103

Brand : GDHY

Terminal : CP Wire

Capacity Tolerance : ±5% ~ ±10%

Material : Polyester Film

Series : Metallized Polyester Film Capacitor

Place Of Original : China

Supplier Type : Manufacturer

Lead : 0.6mm

Color : Green

Encapsulation : Powder

Application : Communication Equipments, Radio Recorder, TV Sets, Led Driver,VCD etc

Contact Now

CL11 2J103 MPE Capacitor CL11 103/630V for LED Driver/ Led Light Polyester Film Capacitor

Technical Parameter

Reference Standards	GB/T 6346 (IEC 60384-11)
Climate Category	55/085/21
Operating Temperature Range	-40℃～+85℃
Capacity Range	0.001～0.47μF
Rated Voltage	50V,63V,100V,250V,400V,630V,1000V(DC)
Capacity Tolerance	±5%(J)；±10%(K)；±20%(M)
Withstand voltage	2.0UR 5S (@20±5%)
Dissipation Factor	tgδ≤0.01 (@20℃, 1KHz)
Insulation Resistance	C≤0.1μF≥30000MΩ C>0.1μF≥10000S

Application

Widely used in DC, Pulsating Circuits like Communication Equipments, Radio Recorder, TV Sets, VCD etc.

Features

●Polyester dielectric

● Inductive winding structure

● Epoxy resin coating

● Spot welding to electrode directly

● Small size and light weight

Product Picture

CL11 Polyester Film Capacitor

Product Shape

CL11 Polyester Film Capacitor

Product Line

CL11 Polyester Film Capacitor

Workshop&Equipment

CL11 Polyester Film Capacitor

Certification

CL11 Polyester Film Capacitor

Exhibition

CL11 Polyester Film Capacitor

Packing Method

CL11 Polyester Film Capacitor
