VISHAY MKP1839 250VDC CBB20 10UF Axial Audio Film Capacitor

Name: VISHAY MKP1839 250VDC CBB20 10UF Axial Audio Film Capacitor
Brand: GDHY
Price: 1 USD

Brand Name : GDHY

Model Number : CBB20251106JX01-01/XPP 106J250VDC

Certification : SGS,ISO

Place of Origin : GUANGZHOU, CHINA

MOQ : 10KPCS

Price : USD 1/PCS

Payment Terms : Western Union, T/T, MoneyGram

Supply Ability : 1KKPCS/MONTH

Delivery Time : 14 DAYS

Packaging Details : CARTON WITH FOAM BOX AND ANIT-CORROSION PROTECT.

BRAND : GDHY

PLACE OF ORIGIN : GUANGZHOU, CHINA

SUPPLIER TYPE : ORIGINAL MANUFACTURER

MODEL NUMBER : CBB20251106JX01-01

CORE : IMPORTED COPPER FOIL

TERMINAL : CP WIRE

CERTIFICATION : ISO,SGS

OPERATION TEMP : -40℃～85℃

CAPACITANCE : 10UF

TOLERANCE : ±5%

RATED VOLTAGE : 250VDC

LIFE EXPECTANCY : 100000h at UN and 70℃,30000h at Urms

DIMENSION : 44MM*38MM*18MM

PRINTING : LASER MARKING

EXPERIENCE : OVER 22 YEARS

COLOR : WHITE

FUNCTION : FLAME RETARDANT EPOXY RESIN

ENCAPSULATION : FLAME RETARDANT EPOXY RESIN

Contact Now

CBB20 0.068UF/400VDC VISHAY MKP1839 AXIAL METALIZED POLYPROPYLENE FILM CAPACITOR FOR AUDIO RADIO/AUDIO AMPLIFIER

Technical Parameter

Reference Standards	GB/T 10190(IEC 60384-16)
Climate Category	40/085/21
Operating Temperature Range	-40℃～85℃ Tmax 105℃
Capacity Range	0.01-40μF
Rated Voltage	250/400/630VDC
Capacity Tolerance	±5%(J)；±10%(K)；±20%(M)
Withstand voltage	1.6UR (5S)
Dissipation Factor	tgδ≤0.0010 (20℃, 1KHz)
Insulation Resistance	C≤0.33μF R≥100000MΩ(at 20℃ 100VDC 1Min) C>0.33 μF RCN≥30000S (at 20℃ 100VDC 1Min)

Specification download: CBB20.pdf

Application

Temperature compensating circuit

Timing oscillation circuit

Audio frequency division circuit

Feature

● Metallized polypropylene film dielectric

● Non-inductive winding structure

● Myla tape with flame retardant epoxy resin at both ends

● Axial tin copper wire leads

● Resistance to high voltage, small tgδ, low temperature rise

Product Picture
