Automotive P15mm 0.33uF DC LINK Film Capacitors

Product Categories

Guangdong Huayu Electronic Company Limited

Contact Now

Name: Automotive P15mm 033uF DC LINK Film Capacitors
Brand: GDHY
Price: 0.7 USD

Brand Name : GDHY

Model Number : C52801334JX08-01

Certification : ISO,SGS

Place of Origin : CHINA

MOQ : 100PCS

Price : USD0.7/PC

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 1000PCS/MONTH

Delivery Time : 14DAYS

Capacity : 0.33uF

Voltage : 800VDC

Size(W*T*H) : 18*10.8*19mm

Pitch : 15mm

Model : C52801334JX08-01

Brand : GDHY

Packing : Plastic Case

Terminal : CP Wire

Capacity Tolerance : Guangzhou

Material : Polypropylnen Film

Series : DC-LINK Capacitor

Place of Original : China

Color : Yellow

Encapsulation : Flame Retardant Epoxy Resin

Application : UPS, Inverter Power Supplies, Welder Power Supplies,Electric Vehicles

Contact Now

C52 0.33uF 800VDC DC LINK CAPACITOR FOR AUTOMOTIVE APPLICATION DC-LINK CAPACITORS IN POWER CONVERTERS

Reference Standards	GB/T 17702, IEC 61071
Operating Temperature Range	-40℃～85℃
Capacity Range	5.0μF ~ 90μF
Rated Voltage	500VDC~1200VDC
Capacity Tolerance	±5%(J); ±10%(K)
Test Voltage between Terminals	1.5UN(DC)60S 25℃±5℃
Test Voltage btw Terminals & Case	1000+2×UN/√2(VAC) 50Hz 60S (min 3000VAC)
Dissipation Factor	tgδ≤1.5×10-3 at 25℃±5℃,100Hz
Insulation Resistance	C•R≥5000S,at 100VDC,25℃±5℃,60S
Life Expectancy	100000h at Ur and ≤70℃

Application

● Widely used in DC-Link Circuits as a filter for Energy Storage.

● Ups, Inverter Power Supplies, Welder Power Supplies, etc.

Feature

● Polypropylene film dielectric

● Plastic shell, flame retardant epoxy resin encapsulation

● Tin coated copper wire

● High pulse current withstand capacity

● Convenient installation

Product Picture
