Polypropylene Film Capacitor For Suppressing Noise Occurring In Power Line

Name: Polypropylene Film Capacitor For Suppressing Noise Occurring In Power Line
Brand: GDHY
Price: 0.085 USD

China Polypropylene Film Capacitor For Suppressing Noise Occurring In Power Line wholesale

Brand Name : GDHY

Model Number : X2 474K310V P22.5

Certification : CQC, KC, VDE, UL, SGS ETC

Place of Origin : GUANGZHOU, CHINA

MOQ : 30KPCS

Price : 0.085 USD/ PCS

Payment Terms : Western Union, MoneyGram, T/T

Supply Ability : 1000 KPCS/ MONTH

Delivery Time : 14 DAYS

Packaging Details : CARTON

PLACE OF ORIGIN : GUANGZHOU, CHINA

SUPPLIER TYPE : ORIGINAL MANUFACTURER

TYPE : POLYPROPYLENE FILM CAPACITOR

MODEL : X2 474K310V P22.5

MATERIAL : POLYPROPYLNEN FILM

OPERATION TEMPERATURE : -40℃～110℃

CAPACITANCE : 0.47UF

TOLERANCE : ±10%

RATED AC VOLTAGE : 310VAC

RATED DC VOLTAGE : 630VDC

PITCH : 22.5MM

DIMENSION : 26*16.5*7MM

ENCAPSULATION : FLAME RETARDANT EPOXY

PACKAGE TYPE : THROUGH HOLE

COLOR : BLUE

CHARACTERISTICS : INTERFERENCE SUPPRESSION; SELF HEALING

CERTIFICATION : CQC, KC, VDE, UL, SGS ETC

APPLICATION : ANTI-INTERFERENCE SITUATIONS SUCH AS POWER SUPPLY ACROSS LINES AND OTHER AC FIELD.

OEM/ODM : YES

MEADIA AVAILABLE : DATASHEET

Contact Now

Polypropylene Film Capacitor For Suppressing Noise Occurring In Power Line Capacitor for suppressing noise occurring in power line of electrical appliances

Technical Parameter

Reference Standards	GB/T 14472 (IEC 60384-14)
Climate Category	40/110/56/B
Operating Temperature Range	-40℃~+110℃
Capacity Range	0.47μF
Rated Voltage	310VAC
Capacity Tolerance	±10%(K)
Withstand voltage	Vt-t:4.3UR (VDC), 2S Vt-c:2100VAC,1min
Insulation Resistance	C≤0.33μF R≥15000MΩ ( 20℃ 100VDC 1Min) C>0.33μF RCN≥5000S ( 20℃ 100VDC 1Min

Specification download: MKP-X2-P - smaller size.pdf

Application

Specially designed for Suppression of Power Electromagnetic Interference, widely applied to anti-interference situations such as power supply across lines and other AC field.

Features

● Metallized polypropylene film dielectronic

● Non-inductive winding structure

● Plastic shell encapsulation

● Withstand over voltage shocks

● Good appearance consistency

Product picture
