Metallized Polypropylene Film Capacitor CBB22 154j250v 0.15uf P10

Name: Metallized Polypropylene Film Capacitor CBB22 154j250v 015uf P10
Brand: GDHY
Price: 1 USD

China Metallized Polypropylene Film Capacitor CBB22 154j250v 0.15uf P10 wholesale

Brand Name : GDHY

Model Number : CBB22 154J250V P10

Certification : SGS,ISO

Place of Origin : GUANGZHOU, CHINA

MOQ : 100KPCS

Price : PLEASE CONTACT US FOR MORE DETAILS

Payment Terms : Western Union, T/T, MoneyGram

Supply Ability : 1KK PCS/MONTH

Delivery Time : 15 WORKING DAYS

Packaging Details : PLASTIC BAG

BRAND : GDHY

SUPPLIER TYPE : ORIGINAL MANUFACTURER

TYPE : METALLIZED POLYPROPYLENE FILM CAPACITOR

STRUCTURE : NON-INDUCTIVE WINDING

CERTIFICATION : SGS, ISO

OPERATION TEMP : -40℃～85℃

CAPACITANCE : 0.15UF

TOLERANCE : ±5%

RATED VOLTAGE : 250VDC

DIELECTRIC : METALLIZED POLYPROPYLENE FILM

ENCAPSULATION : POWDER

DIMENSION : MAX13.0*6.0*10.0 MM

PITCH : 10MM

LEAD DIA : 0.6MM

APPLICATION : DC,AC,PULSE CIRCUITS

Contact Now

Metallized Polypropylene Film Capacitor CBB22 154j250v 0.15uf P10 0.15UF 250V 5% CBB22 METALLIZED POLYPROPYLENE FILM CAPACITOR FREE SAMPLE AVAILABLE

Technical Parameter

Reference Standards	GB/T 10190(IEC 60384-16)
Climate Category	40/085/21
Operating Temperature Range	-40℃～85℃
Capacity Range	0.15μF
Rated Voltage	250VDC
Pitch	10MM
Capacity Tolerance	±5%(J);±10%(K)
Withstand voltage	Vt-t:1.6UN 5S (at20 ±5%)
Dissipation Factor	tgδ≤0.0010 (20℃, 1KHz)
Insulation Resistance	C≤0.33μF R≥30000MΩ (at20℃ 100VDC 1Min)
Maximum Pulse Rise Time (dv/dt)	220(V/μS)

Specification download: CBB22.pdf

Application

Widely used in high frequency, DC, AC, Pulse Circuits, and the S-correction circuits of the display device.

Feature

● Metallized polypropylene film dielectric

● Non-inductive winding structure

● Flame retardant epoxy resin powder encapsulation

● Resistance to high voltage, small tgδ, low temperature rise

Product Picture
