CBB22 Film Capacitor 0.1UF 104j250v P=10mm Free Sample Available

Product Categories

Guangdong Huayu Electronic Company Limited

Contact Now

Name: CBB22 Film Capacitor 01UF 104j250v P10mm Free Sample Available
Brand: GDHY
Price: 1 USD

Brand Name : GDHY

Model Number : CBB22 0.1UF 250V P10

Certification : SGS,ISO

Place of Origin : GUANGZHOU, CHINA

MOQ : 100KPCS

Price : PLEASE CONTACT US FOR MORE DETAILS

Payment Terms : Western Union, T/T, MoneyGram

Supply Ability : 1KK PCS/MONTH

Delivery Time : 15 WORKING DAYS

Packaging Details : PLASTIC BAG

TYPE : METALLIZED POLYPROPYLENE FILM CAPACITOR

BRAND : GDHY

DIELECTRIC : METALLIZED POLYPROPYLENE FILM

CAPACITANCE : 0.10UF

RATED VOLTAGE : 250VDC

TOLERANCE : ±5%(J);±10%(K)

PITCH : 10MM

DIMENSION : MAX13.0*5.5*9.5 MM

SUPPLIER TYPE : ORIGINAL MANUFACTURER

STRUCTURE : NON-INDUCTIVE WINDING STRUCTURE

LEAD DIA : 0.6MM

CERTIFICATION : SGS, ISO

APPLICATION : HIGH FREQUENCY,DC,AC,S-CORRECTION CIRCUITS

Contact Now

CBB22 Film Capacitor 0.1UF 104j250v P=10mm Free Sample Available METALLIZED POLYPROPYLENE FILM CAPACITOR CBB22 0.10UF 104/250V 5% MANUFACTURER

Technical Parameter

Reference Standards	GB/T 10190(IEC 60384-16)
Capacitance	0.10μF
Rated Voltage	250VDC
Pitch	10MM
Encapsulation	Powder
Climate Category	40/085/21
Operating Temperature Range	-40℃～85℃
Tolerance	±5%(J);±10%(K)
Withstand voltage	Vt-t:1.6UN 5S (at20 ±5%)
Dissipation Factor (DF)	tgδ≤0.0010 (20℃, 1KHz)
Insulation Resistance	C≤0.33μF R≥30000MΩ (at20℃ 100VDC 1Min)
Maximum Pulse Rise Time (dv/dt)	220(V/μS)

Application

This series product is designed for high frequency, direct current, AC, Pulse Circuits, and the S-correction circuits of the display device, etc.

Feature

● Metallized polypropylene film dielectric

● Non-inductive winding structure

● Flame retardant epoxy resin powder encapsulation

● Resistance to high voltage, small tgδ, low temperature rise

● Datasheet available, customizable products available on request

● Good appearance consistency

Product Picture
