472nf 1000VDC High Voltage Metallized Polypropylene Film Capacitors

Name: 472nf 1000VDC High Voltage Metallized Polypropylene Film Capacitors
Brand: GDHY
Price: 0.1 USD

Brand Name : GDHY

Model Number : CBB81 4721KV

Certification : SGS,ISO

Place of Origin : GUANGZHOU, CHINA

MOQ : 20KPCS

Price : 0.1 USD/ PCS

Payment Terms : Western Union, MoneyGram, T/T

Supply Ability : 1000 KPCS/ MONTH

Delivery Time : 15 DAYS

Packaging Details : CARTON

PLACE OF ORIGIN : GUANGZHOU, CHINA

SUPPLIER TYPE : ORIGINAL MANUFACTURER

TYPE : POLYPROPYLENE FOIL CAPACITOR

MODEL : CBB81 4721KV21

MATERIAL : Metallized polypropylene film

OPERATION TEMPERATURE : -40℃～105℃

CAPACITANCE : 472nF

TOLERANCE : ±5%,±10%,±20%

RATED DC VOLTAGE : 800VDC,1000VDC,1200VDC,1600VDC,2000VDC

PITCH : 15MM

DIMENSION : 24*13.5*20MM

ENCAPSULATION : Flame retardant epoxy resin powder encapsulation

PACKAGE TYPE : non-inductive construction

COLOR : Red

CHARACTERISTICS : Small tgδ, low internal temperature rise

CERTIFICATION : VDE, UL, SGS，ISO

APPLICATION : Display, Color TV Reverse Circuit Suitable for High Pulse and High Current Circuits;Suitable for High Pulse and High Current Circuits

OEM/ODM : both

Specification data : Supply if need

Contact Now

472nf 1000VDC High Voltage Metallized Polypropylene Film Capacitors

Technical Parameter

Reference Standards	GB/T 14579 (IEC 60384-17)
Climate Category	40/85/21
Operating Temperature Range	-40℃~85℃,Tmax105℃
Capacity Range	0.001uf-0.1uf
Rated Voltage	800VDC,1000VDC,1200VDC,1600VDC,2000VDC
Capacity Tolerance	±5%,±10%,±20%
Withstand voltage	Vt-t:1.75Un 5S (at 20±5℃)
Insulation Resistance	R C≥3000s；at 1000VDC;25℃ ±5℃,60s

Application

Display, Color TV Reverse Circuit Suitable for High Pulse and High Current Circuits;

Suitable for High Pulse and High Current Circuits

Features

● Metallized polypropylene film foil dielectronic

● Non-inductive winding structure

● Flame retardant e poxy resin powder encapsulation

● Small tgδ, low internal temperature rise

● Negative electricity capacity temperature ratio

Product picture
