2.2uF 225nF High Frequency Film Capacitor for lighting / control / auto

Name: 22uF 225nF High Frequency Film Capacitor for lighting control auto
Brand: GDHY
Price: 0.1 USD

China 2.2uF 225nF High Frequency Film Capacitor for lighting / control / auto wholesale

Brand Name : GDHY

Model Number : CBB22 225J630V 27mm

Certification : SGS,ISO

Place of Origin : GUANGZHOU, CHINA

MOQ : 30KPCS

Price : 0.1 USD/ PCS

Payment Terms : Western Union, MoneyGram, T/T

Supply Ability : 1000 KPCS/ MONTH

Delivery Time : 14 DAYS

Packaging Details : PAPER CARTON

PLACE OF ORIGIN : GUANGZHOU, CHINA

SUPPLIER TYPE : RAW MANUFACTURE

TYPE : Non-inductive winding structure capacitor

MODEL : CBB22 225J630V 27mm

MATERIAL : POYESTER FILM-INSULATOR

OPERATION TEMPERATURE : -40℃～85℃

CAPACITANCE : 225nF

TOLERANCE : ±5%

RATED DC VOLTAGE : 630VDC

PITCH : 27MM

DIMENSION : 28.5*24*18MM

ENCAPSULATION : Flame retardant epoxy resin powder coating

PACKAGE TYPE : Through Hole

COLOR : red

CHARACTERISTICS : Resistance to high voltage, small tgδ, low temperature rise

CERTIFICATION : CQC, KC, VDE, UL, SGS ETC

APPLICATION : led lighting /control/ auto

OEM/ODM : OEM/ODM

Circuit Type : Isolated

Contact Now

2.2uF 225nF High Frequency Film Capacitor for lighting / control / auto 2.2uF 225nF Good price film capacitor High Frequency, DC, AC,S-correction circuits of the display device

Technical Parameter

Reference Standards	GB/T 10190 (IEC 60384-16)
Climate Category	40/85/21
Operating Temperature Range	-40℃~85℃
Capacity Range	0.01uf-2.2uf
Rated Voltage	100VDC,250VDC,400VDC,630V
Capacity Tolerance	±5%(J);±10%(K)±20%(M)
Withstand voltage	Vt-t:1.6Un 5s (at 20±5℃)
Insulation Resistance	R C≥3000s；at 1000VDC;25℃ ±5℃,60s

Application

lighting /control/ auto, General Purpose

Features

● Metallized polypropylene film dielectronic

● Non-inductive winding structure

● Plastic shell encapsulation

● Good appearance consistency

Product picture
