Name: CBB22 223J630V P10 Kapasitor Polypropylene Film Capacitor Condensateur MPP Epoxy Resin Coating
Brand: GDHY
Price: 1 USD

Brand Name : GDHY

Model Number : CBB22 223J630V P10

Certification : SGS,ISO

Place of Origin : GUANGZHOU, CHINA

MOQ : 100KPCS

Price : PLEASE CONTACT US FOR MORE DETAILS

Payment Terms : Western Union, T/T, MoneyGram

Supply Ability : 1KK PCS/MONTH

Delivery Time : 15 WORKING DAYS

Packaging Details : PLASTIC BAG

DIELECTRIC : METALLIZED POLYPROPYLENE FILM

CAPACITY : 0.022UF/22NF

RATED VOLTAGE : 630V

DIMENSION : 13.0*6.5*10.5MM

PITCH : 10MM

COLOR : RED

LEADS : RADIAL LEADS OF TINNED WIRE

ADVANTAGES : SELF HEALING, HIGH INSULATION RESISTANCE

Contact Now

CBB22 223J630V 0.022UF METALLIZED POLYPROPYLENE FILM CAPACITOR ENERGY SAVING LAMP PITCH10MM

Model number	B2230630-D-10-4R
Reference Standards	GB/T 10190(IEC 60384-16)
Climate Category	40/085/21
Operating Temperature Range	from -40℃ to +85℃
Capacity	0.022μF
Rated Voltage	630V
Pitch	10mm
Dimension	13.06.510.5mm
Capacity Tolerance	±5%(J);±10%(K)
Withstand voltage	Vt-t:1.6UN 5S (at20 ±5%)
Dissipation Factor	tgδ≤0.0010 (20℃, 1KHz)
Maximum Pulse Rise Time (dv/dt)	320(V/μS)
Insulation Resistance	RCN≥30000S (at20℃ 100VDC 1Min)

Application

Suitable for DC, pulse, frequency and current circuits, and the S-shaping correction circuits of the display device.

Widely used in Lighting industry, Audio industry, Automation industry, Power industry, Household appliance, Telecommunication industry.

Feature

● Low-dissipation factor with frequency

● Non-inductive winding structure

● Good stability and reliability, high insulation resistance

● Good self-healing

● Resistance to high voltage, small tgδ and inherent temperature rise

Product Picture
