CBB81 0.047UF 473J 2000V PITCH 21 POLYPROPYLENE FILM CAPACITOR SWITCHING POWER
Technical Parameter
| Model number | T4732000-D-21-1R |
| Reference Standards | GB/T 14579(IEC 60384-17) |
| Climate Category | 40/085/21 |
| Operating Temperature Range | from -40℃ to +85℃, Tmax 105℃ |
| Capacity | 0.047μF/473 |
| Rated Voltage | 2000V/2KV |
| Pitch | 21MM |
| Dimension (W*H*T) | 24*14*21MM |
| Lead dia | 0.8MM |
| Capacity Tolerance | ±5%(J);±10%(K) |
| Withstand voltage | Vt-t:1.75UN 5S (at20 ±5%) |
| Dissipation Factor | tgδ≤0.0010 (20℃, 1KHz) |
| Maximum Pulse Rise Time (dv/dt) | 30000(V/μS) |
| Insulation Resistance | >50000MΩ (at 20℃ 1Min) |
Specification download: CBB81.pdf
Application
● Most suitable for high-voltage and large pulse current and especially large current circuits. same suitable for high-voltage and high pulse circuits for switching power electronic ballast and other electronic equipment.
● Ideal for high AC current applications, such as CRT deflection for R-F generators and pulse-forming networks.
● Can be applied in AC/Motor, power, lighting, air conditioner, high voltage, fan, automobile.
Feature
● Metallized polypropylene film foil dielectric
● Non-inductive winding structure, coated with flame retardative epoxy resin which provides from humidity and mechanical damage
● Have self-healing property
● Very small dissipation factor at high-frequency and high insulation resistance
● Resistance to high voltage, small tgδ and inherent temperature rise
Product Picture
Product Shape
Production
Workshop&Equipment
Packing method
Certificate
Exhibition
