102uF Metallized CBB Polypropylene Film Capacitor 1250VDC

Name: 102uF Metallized CBB Polypropylene Film Capacitor 1250VDC
Brand: GDHY
Price: 0.1 USD

Brand Name : GDHY

Model Number : CBB28-102J1250V-10RN

Certification : SGS,ISO

Place of Origin : GUANGDONG, CHINA

MOQ : 30KPCS

Price : 0.1 USD/ PCS

Payment Terms : Western Union, MoneyGram, T/T

Supply Ability : 1000 KPCS/ MONTH

Delivery Time : 14 DAYS

Packaging Details : PAPER CARTON

PLACE OF ORIGIN : GUANGDONG, CHINA

TYPE : polypropylene film capacitor

RATED DC VOLTAGE : 1250VDC

MATERIAL : Polypropylene Film

OPERATION TEMPERATURE : -40 ℃～85℃, Tmax+105℃

SUPPLIER TYPE : ORIGINAL MANUFACTURER

MODEL : CBB28-102J1250V-10RN

COLOR : Red

APPLICATION : Suitable for filtering, coupling, bypass, temperature compensation, step-down circuit, timing circuit, industrial instrument, and automatic control system

DIMENSION : 20MM *14MM*9MM

TOLERANCE : ±5%;±10%;±20%

ENCAPSULATION : plastic package, Sealed with epoxy resin

CAPACITANCE : 102nF

PITCH : 10MM

Terminals : Clip

CHARACTERISTICS : Metal plastic package, Sealed with epoxy resin

OEM/ODM : OEM/ODM

Contact Now

102uF Metallized CBB Polypropylene Film Capacitor 1250VDC 102uF Metallized Polypropylene Film Capacitor 1250VDC Good Price

Technical Parameter

Reference Standards	GB/T 10190 (IEC 60384-16)
Climate Category	40/85/21
Operating Temperature Range	-40℃~85℃, Tmax 105℃
Capacity Range	0.001uf-2.2uf
Rated Voltage	100VDC,250VDC,400VDC,630VDC
Capacity Tolerance	±5%(J);±10%(K);±20%(m)
Withstand voltage	Vt-t:1.6Un 5S (at 20±5℃)
Insulation Resistance	R C≥3000s；at 100VDC;25℃ ±5℃,60s

Application

Pulse, high frequency and large current occasions, used in electrical appliances requiring high frequency, high current and high stability.

Features

Metallized polypropylene film, epoxy resin encapsulation, low high frequency loss, good insulation, good self-healing effect.
Very small dissipation factor at high-frequency, very small inner temperature rise.
Good stability of capacitance, excellent insulation resistance property.
excellent self-healing property.
