1600VDC 103uF Metallized Polypropylene Film Capacitor

Name: 1600VDC 103uF Metallized Polypropylene Film Capacitor
Brand: GDHY
Price: 0.1 USD

Brand Name : GDHY

Model Number : CBB81-103J1600V-20RN

Certification : SGS,ISO

Place of Origin : GUANGDONG, CHINA

MOQ : 30KPCS

Price : 0.1 USD/ PCS

Payment Terms : Western Union, MoneyGram, T/T

Supply Ability : 1000 KPCS/ MONTH

Delivery Time : 14 DAYS

Packaging Details : PAPER CARTON

PLACE OF ORIGIN : GUANGDONG, CHINA

TYPE : polypropylene film capacitor

RATED DC VOLTAGE : 1600VDC

MATERIAL : Polypropylene Film

OPERATION TEMPERATURE : -40 ℃～85℃, Tmax+105℃

SUPPLIER TYPE : ORIGINAL MANUFACTURER

MODEL : CBB81-103J1600V-20RN

COLOR : Red

APPLICATION : Suitable for filtering, coupling, bypass, temperature compensation, step-down circuit, timing circuit, industrial instrument, and automatic control system

DIMENSION : 30MM *17.5MM*10.5MM

TOLERANCE : ±5%;±10%;±20%

ENCAPSULATION : plastic package, Sealed with epoxy resin

CAPACITANCE : 103nF

PITCH : 20MM

Terminals : Clip

CHARACTERISTICS : Metal plastic package, Sealed with epoxy resin

OEM/ODM : OEM/ODM

Contact Now

1600VDC 103uF Metallized Polypropylene Film Capacitor 103uF Metallized Polypropylene Film Capacitor 1600VDC New Original Supplier

Technical Parameter

Reference Standards	GB/T 14579 (IEC 60384-17)
Climate Category	40/85/21
Operating Temperature Range	-40℃~85℃, Tmax 105℃
Capacity Range	0.001uf-0.1uf
Rated Voltage	800VDC,1000VDC,1200VDC,1600VDC,2000VDC
Capacity Tolerance	±5%(J);±10%(K);±20%(m)
Withstand voltage	Vt-t:1.6Un 5S (at 20±5℃)
Insulation Resistance	R C≥3000s；at 100VDC;25℃ ±5℃,60s

Application

Our products are widely used for lighting industry, audio industry ,automation industry,
power supply,telecommunication industry and the household appliance.

Features

Metallized polypropylene film, epoxy resin encapsulation, low high frequency loss, good insulation, good self-healing effect.
Very small dissipation factor at high-frequency, very small inner temperature rise.
Good stability of capacitance, excellent insulation resistance property.Very low loss at high frequency,suitable for high current
High insulation resistance,long life due to self-healing effect

Widely used in high frequency,DC,AC and pulse circuits
