9mm Height 1UF 400VDC Polypropylene Film Capacitor

Name: 9mm Height 1UF 400VDC Polypropylene Film Capacitor
Brand: GDHY
Price: 0.5 USD

China 9mm Height 1UF 400VDC Polypropylene Film Capacitor wholesale

Brand Name : GDHY

Model Number : CBB22-105K400V-20RN-1R

Certification : SGS,ISO

Place of Origin : GUANGZHOU, CHINA

MOQ : 10KPCS

Price : 0.5 USD/ PCS

Payment Terms : Western Union, MoneyGram, T/T

Supply Ability : 1000 KPCS

Delivery Time : 14 DAYS

Packaging Details : plastic bag and carton

Place Of Origin : Guangzhou, China

Supplier Type : Original Manufacturer

Classification : Polypropylene Film Capacitor

Model number : B1050400-D-20-1R

material : Metallized polypropylene film

Operating Temperature Range : -40℃～85℃

Capacitance : 1UF

Capacity Tolerance : ±5%

Rated DC Voltage : 400VDC

Pitch : 20±1.5mm

height : 9mm

width : 23mm

thickness : 15.5mm

Contact Now

1UF 400VDC,Polypropylene Film Capacitor,High quality polypropylene film

9mm Height 1UF 400VDC Polypropylene Film Capacitor

Technical Parameter

Reference Standards	GB/T 10190(IEC 60384-16)
Climate Category	40/085/21
Operating Temperature Range	-40°℃~85°℃
Capacitance	1μF
Rated Voltage	400VDC
Capacity Tolerance	±5%
Withstand voltage	Vtet:1.6UN 5S (at20±5℃)
Insulation Resistance	C≤0.33uF R≥100000MQ(at20°℃ 100VDC 1Min) C>0.33 uF RCN≥30000s (at20℃ 100VDC 1Min)

Specification download: CBB22.pdf

Application

Widely used in High Frequency, DC, AC, Pulse Circuits. S-correction circuits of the display device

Features

● Metallized polypropylene film dielectric

● Non-inductive winding structure

● Flame retardant epoxy resin powder encapsulation

● Resistance to high voltage, small tg6,low temperature rise

Product picture

9mm Height 1UF 400VDC Polypropylene Film Capacitor

Product shape

9mm Height 1UF 400VDC Polypropylene Film Capacitor

Production

9mm Height 1UF 400VDC Polypropylene Film Capacitor

Workshop& Equipment

9mm Height 1UF 400VDC Polypropylene Film Capacitor

Packing method

9mm Height 1UF 400VDC Polypropylene Film Capacitor

Certificate

9mm Height 1UF 400VDC Polypropylene Film Capacitor

Exhibition

9mm Height 1UF 400VDC Polypropylene Film Capacitor
