0.68UF 684/630V P20 CBB22 Polypropylene Film Capacitor Electronic Components

Product Categories

Guangdong Huayu Electronic Company Limited

Contact Now

Name: 068UF 684630V P20 CBB22 Polypropylene Film Capacitor Electronic Components
Brand: GDHY
Price: 0.1 USD

Brand Name : GDHY

Model Number : CBB22 684J630V P20

Certification : SGS,ISO

Place of Origin : GUANGDONG, CHINA

MOQ : 30KPCS

Price : 0.1 USD/ PCS

Payment Terms : Western Union, MoneyGram, T/T

Supply Ability : 1000 KPCS/ MONTH

Delivery Time : 14 DAYS

Packaging Details : PAPER CARTON

PRODUCT TYPE : CBB POLYPROPYLENE FILM CAPACITOR

MODEL CODE : B6840630-D-20-2Y

CAPACITANCE : 0.68UF/680NF/684

RATED VOLTAGE : 630VDC

DIMENSION : 23*11*17

PITCH : 20MM

PRINTING : LASER PRINTING

SHAPE : RECTANGULAR

COLOR : RED

PACKING : IN BULK

Contact Now

0.68UF 684J630V P20 CBB22 POLYPROPYLENE FIML CAPACITOR HIGH PRESSURE LOW NOISE

Technical Parameter

Reference Standards	GB/T 10190 (IEC 60384-16)
Climate Category	40/085/21
Operating Temperature Range	-40℃~85℃
Capacity Range	0.68uf/680nf/684
Rated Voltage	630VDC
Capacity Tolerance	±5%(J);±10%(K)
Withstand voltage	2Un 5S (at 20±5℃)
Insulation Resistance	≥30000MΩ；at 100VDC;20℃ ±5℃,60s

● Suitable for a variety of AC and DC pulse larger circuits.

● Can also be applied in high frequency, direct current and pulse circuits.

● Timing with high stability, SMPS and TV set, Lighting, Filtering.

● Metallized polypropylene film capacitors.

● Low leakage, stable capacity, good self-healing.

● Flame retardant epoxy resin wrapping

● Very low loss at high frequency, small internal temperature rise.

● High insulation resistance, excellent self-healing property and long life.

● Metallized polypropylene inner series structure

● High voltage resistance

● Moisture resistance, able to withstand overpressure shocks.
