0.39UF Polypropylene Film Capacitor 394v 630V P20 CBB22 Lamp Electric Circuits

Name: 039UF Polypropylene Film Capacitor 394v 630V P20 CBB22 Lamp Electric Circuits
Brand: GDHY
Price: 0.1 USD

China 0.39UF Polypropylene Film Capacitor 394v 630V P20 CBB22 Lamp Electric Circuits wholesale

Brand Name : GDHY

Model Number : CBB22 394J630V P20

Certification : SGS,ISO

Place of Origin : GUANGDONG, CHINA

MOQ : 30KPCS

Price : 0.1 USD/ PCS

Payment Terms : Western Union, MoneyGram, T/T

Supply Ability : 1000 KPCS/ MONTH

Delivery Time : 14 DAYS

Packaging Details : PAPER CARTON

BRAND : GDHY

PRODUCT TYPE : CBB POLYPROPYLENE FILM CAPACITOR

CASE CODE : B3940630-D-20-1R

CAPACITANCE : 0.39UF/390NF/394

RATED VOLTAGE : 630VDC

DIMENSION : 23*8*14.5MM

PITCH : 20MM

PACKING : IN BULK

Contact Now

POLYPROPYLENE FIML CAPACITOR 0.39UF 394J630V P20 CBB22 ELECTRIC CIRCUITS ENERGY SAVING LAMP

Technical Parameter

Reference Standards	GB/T 10190 (IEC 60384-16)
Climate Category	40/085/21
Operating Temperature Range	-40℃~85℃
Capacitance	0.39uf/390nf/394
Rated Voltage	630VDC
Capacity Tolerance	±5%(J);±10%(K)
Withstand voltage	2Un 5S (at 20±5℃)
Insulation Resistance	≥30000MΩ；at 100VDC;20℃ ±5℃,60s

Application

● Widely applied in all kind of electronic filtering, DC-blocking, bypass, coupling of reduction voltage, DC and pulse circuit, especially for all kinds of energy saving lamps and electronic rectifiers.

● Can also be applied in high frequency, direct current and pulse circuits.

● Timing with high stability, SMPS and TV set, Lighting, Filtering.

Features

● Metallized polypropylene film capacitors.

● High nsulation resistance, low loss, low internal temperature rise.

● Flame retardant epoxy resin wrapping

● Good stability, excellent frequency charactristic.

● High voltage resistance

● Moisture resistance, able to withstand overpressure shocks.
