CBB22 0.82UF 400V P15 Polypropylene Film Capacitor 5% Audio Industry Lighting

Product Categories

Guangdong Huayu Electronic Company Limited

Contact Now

Name: CBB22 082UF 400V P15 Polypropylene Film Capacitor 5 Audio Industry Lighting
Brand: GDHY
Price: 0.1 USD

Brand Name : GDHY

Model Number : CBB22 824J400V P15

Certification : SGS,ISO

Place of Origin : GUANGDONG, CHINA

MOQ : 30KPCS

Price : 0.1 USD/ PCS

Payment Terms : Western Union, MoneyGram, T/T

Supply Ability : 1000 KPCS/ MONTH

Delivery Time : 14 DAYS

Packaging Details : PAPER CARTON

BRAND : GDHY

BRAND TYPE : ORIGINAL MANUFACTURER

ADVANTAGE : 20+ YEARS EXPERIENCE

PRODUCT TYPE : CBB POLYPROPYLENE FILM CAPACITOR

CASE CODE : B8240400-D-15-2U

CAPACITANCE : 0.82UF/820NF/824

RATED VOLTAGE : 400V

DIMENSION : 18*8*13MM

PITCH : 15MM

COLOR : RED

Contact Now

CBB22 824/400V PITCH15 5% POLYPROPYLENE FIML CAPACITOR AUDIO INDUSTRY LIGHTING INDUSTRY

Technical Parameter

Reference Standards	GB/T 10190 (IEC 60384-16)
Climate Category	40/085/21
Operating Temperature Range	-40℃~85℃
Capacitance	0.82uf/820nf/824
Rated Voltage	400V
Capacity Tolerance	±5%(J);±10%(K)
Withstand voltage	2Un 5S (at 20±5℃)
Insulation Resistance	≥30000MΩ；at 100VDC;20℃ ±5℃,60s

● Widely applied in the resinant circuit, the bypass circuit and a high frequency high voltage circuits.

● Can also be applied in high frequency, direct current and pulse circuits, for all kinds of energy saving lamps and electronic rectifiers.

● Timing with high stability, SMPS and TV set, Lighting, Filtering.

● Metallized polypropylene film capacitors.

● High insulation resistance, low internal temperature rise.

● Flame retardant epoxy resin wrapping

● Good stability, excellent frequency charactristic.

● High voltage resistance, small dielectric loss.
