Brand Name : GDHY
Model Number : CBB81-562J1600V-15RUN
Certification : SGS,ISO
Place of Origin : GUANGDONG, CHINA
MOQ : 30KPCS
Price : 0.1 USD/ PCS
Payment Terms : Western Union, MoneyGram, T/T
Supply Ability : 1000 KPCS/ MONTH
Delivery Time : 14 DAYS
Packaging Details : PAPER CARTON
PLACE OF ORIGIN : GUANGDONG, CHINA
TYPE : Film Capacitor
MATERIAL : Polypropylene Film
COLOR : Red
APPLICATION : suitable for high-voltage and high pulse circuits for switching power electronic ballast and other electronic equipment
DIMENSION : 24MM *19MM*12MM
TOLERANCE : ±5%;±10%;
SUPPLIER TYPE : ORIGINAL MANUFACTURER
RATED DC VOLTAGE : 1600VDC
ENCAPSULATION : flame-retardant epoxy resin coating, radial CP wire.
MODEL : CBB81-562J1600V-15RUN
CAPACITANCE : 562nF
PITCH : 15MM
Terminals : Clip
OPERATION TEMPERATURE : -40 ℃~85℃, Tmax+105℃
CHARACTERISTICS : Low equivalent series resistance Low equivalent series inductance
OEM/ODM : OEM/ODM
Reference Standards | GB/T 10190 (IEC 60384-16) |
Climate Category | 40/85/21 |
Operating Temperature Range | -40℃~85℃ |
Capacity Range | 0.01uf-2.2uf |
Rated Voltage | 100VDC,250VDC,400VDC,630VDC |
Capacity Tolerance | ±5%(J);±10%(K);±20%(m) |
Withstand voltage | Vt-t:1.6Un 5S (at 20±5℃) |
Insulation Resistance | R C≥3000s;at 100VDC;25℃ ±5℃,60s |
Application
Features
Product shape
Production
Workshop& Equipment
Packing method
Certificate
Exhibition
![]() |
Red 562nF CBB Polypropylene Film Capacitor 1600VDC Images |
