104nF Axial Audio Film Capacitor Metallized Polypropylene 630VDC CBB20

Name: 104nF Axial Audio Film Capacitor Metallized Polypropylene 630VDC CBB20
Brand: GDHY
Price: 0.1 USD

Brand Name : GDHY

Model Number : CBB20631104JX08-01

Certification : SGS,ISO

Place of Origin : GUANGZHOU,CHINA

MOQ : 30KPCS

Price : 0.1 USD/ PCS

Payment Terms : Western Union, MoneyGram, T/T

Supply Ability : 1000 KPCS/ MONTH

Delivery Time : 14 DAYS

Packaging Details : CARTON

TYPE : polypropylene film capacitor

PLACE OF ORIGIN : GUANGZHOU,CHINA

SUPPLIER TYPE : Original manufacturer

Terminal : Axial leads

MODEL : CBB20631104JX08-01

MATERIAL : Thin film is used as electrolyte, epoxy resin potting

CHARACTERISTICS : Thin film is used as electrolyte, epoxy resin potting, good self-healing, high reliability, low loss, superior electrical performance, mainly used for high-frequency filtering, and crossover, and is used in communication and industrial power supply equipme

OPERATION TEMPERATURE : -40℃～85℃

APPLICATION : It is widely used in filtering, noise reduction, and low-pulse circuits to suppress loop compensation coupling, frequency division, and bypass filter resonance start

RATED DC VOLTAGE : 250VDC,400VDC,630VDC

COLOR : YELLOW

LENGTH : 38MM

ENCAPSULATION : Flame retardant epoxy resin powder encapsulation

TOLERANCE : ±5;%±10%;±20%

CAPACITANCE : 104nF

CERTIFICATION : CQC, KC, VDE, SGS

DIMENSION : 20.5MM，length 38mm

Media Available : datasheet, Photo

Contact Now

104nF Axial Audio Film Capacitor Metallized Polypropylene 630VDC CBB20 104nF Axial Audio Grade Film Capacitor Metallized Polypropylene 630VDC CBB20

Technical Parameter

Reference Standards	GB/T 10190 (IEC 60384-16)
Climate Category	40/085/21
Operating Temperature Range	-40℃~85℃,Tmax 105℃
Capacity Range	0.01uf-40uf
Rated Voltage	100VDC,250VDC,400VDC,630VDC
Capacity Tolerance	±5%(J);±10%(K);±20%(m)
Withstand voltage	Vt-t:1.75Un 5S (at 20±5℃)
Insulation Resistance	R C≥3000s；at 1000VDC;25℃ ±5℃,60s

Application

It is widely used in filtering, noise reduction, and low-pulse circuits to suppress loop compensation coupling, frequency division, and bypass filter resonance start.
Often used in displays, power supplies, energy-saving lamps, program-
controlled switches, speakers, audio amplifiers, instruments, etc.
Circuits and electronic devices that generate electromagnetic interference from power sources

Features

Non-inductive construction and self-healing property.
* Good soldering ability.
* Low dissipation factor and high insulation resistance.
* High stability of capacitance and reliability.

Product picture
