C52 3.3uf 400v DC LINK Film Capacitors TDK B32778m

Name: C52 33uf 400v DC LINK Film Capacitors TDK B32778m
Brand: GDHY
Price: 1 USD

China C52 3.3uf 400v DC LINK Film Capacitors TDK B32778m wholesale

Brand Name : GDHY

Model Number : C52 3.3UF/400V

Certification : ISO,SGS

Place of Origin : GUANGZHOU, CHINA

MOQ : 200PCS

Price : PLEASE CONTACT US FOR DETAILS

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : MORE THAN 1KPCS/MONTH

Delivery Time : 15 WORKING DAYS

Packaging Details : PLASTIC BAG

Type : DC-LINK Capacitor

Brand : GDHY

Capacitance : 3.3UF

Rated voltage : 400V

Dielectric : Polypropylene film

Features : Plastic shell, dry resin infusion

Advantage : Replace electrolytic capacitors, better performance and longer life

Lead type : Tinned copper wire

Supplier type : Original manufacturer

Contact Now

CUSTOMIZABLE METALLIZED POLYPROPYLENE FILM CAPACITORS (MKP) C52 3.3UF 400V (SAME AS TDK DC LINK CAPACITORS B32778M) CHARGING PILE

Technical Parameter

Model code	C52401335JX10-01
Capacitance	3.3μF
Rated Voltage	400V
Reference Standards	GB/T 17702 IEC 61071
Operating Temperature Range	-40℃~70℃ Tmax 105℃
Capacity Tolerance	±5%(J)
Dissipation Factor	tgδ≤1.5X 10-3 ( at25℃±5℃, 100Hz)
Insulation Resistance	C•R≥5000S (at100VDC,at25℃±5℃,1Min)
Flame retardation	UL94V-0
Life Expectancy	100000h at UN and ≤70℃

Datasheet download:C52.pdf

Application

● This product is designed for DC-Link circuits to store energy. For example, in electric vehicle applications, the DC link capacitor is used as a load-balacing energy storage device.

● The performance of this product is better than electrolytic capacitors, and its life expectancy is longer.

● Also used in UPS, all kinds of frequency converter and inverter power supply; Pure electric and hybrid cars, etc.

Feature

● Polypropylene film dielectric

● Plastic shell coating, dry resin infusion

● Tinned copper wire

● High pulse current and high dv/dt; low ESL/ESR

● Small szie, easy installation

● Stabe performance, long life.

Product Picture
