22uF 224nF Metallized Polyester Film Capacitors CL21 250V

Name: 22uF 224nF Metallized Polyester Film Capacitors CL21 250V
Brand: GDHY
Price: 0.1 USD

Brand Name : GDHY

Model Number : CBB21 224J250 25

Certification : SGS,ISO

Place of Origin : GUANGZHOU,CHINA

MOQ : 30KPCS

Price : 0.1 USD/ PCS

Payment Terms : Western Union, MoneyGram, T/T

Supply Ability : 1000 KPCS/ MONTH

Delivery Time : 14 DAYS

Packaging Details : CARTON

TYPE : Metal polypropylene film capacitor

SUPPLIER TYPE : Original manufacturer

CHARACTERISTICS : Wide range of capacity and small volume

Terminal : Double Fast

MODEL : CBB21 224J250 25

MATERIAL : Metal polypropylene

PITCH : 25MM

PLACE OF ORIGIN : GUANGZHOU,CHINA

Circuit Type : Isolated

OPERATION TEMPERATURE : -40℃～85℃

DIMENSION : 28*20*8MM

TOLERANCE : ±5%;±10%

CAPACITANCE : 224nF

Media Available : datasheet, Photo

ENCAPSULATION : Epoxy powder coating

APPLICATION : DC, VHF signal isolation, bypass and coupling circuits Widely used in filtering, noise reduction and low pulse circuits;Widely used in filtering, noise reduction and low pulse circuits

RATED DC VOLTAGE : 100VDC,160VDC,250VDC,400VDC,630VDC

COLOR : red

CERTIFICATION : CQC, KC, VDE, SGS ETC

Contact Now

22uF 224nF Metallized Polyester Film Capacitors CL21 250V

Technical Parameter

Reference Standards	GB/T 7332 (IEC 60384-2)
Climate Category	55/105/21
Operating Temperature Range	-55℃~85℃,Tmax 105℃
Capacity Range	0.01uf-10uf
Rated Voltage	100VDC,250VDC,400VDC,630VDC
Capacity Tolerance	±5%(J);±10%(K);±20%(m)
Withstand voltage	Vt-t:1.75Un 5S (at 20±5℃)
Insulation Resistance	R C≥3000s；at 1000VDC;25℃ ±5℃,60s

Application

DC, VHF signal isolation, bypass and coupling circuits Widely used in filtering, noise reduction and low pulse circuits;
Widely used in filtering, noise reduction and low pulse circuits

Features

1)This is constructed from metallized polypropylene film dielectric, non-inductive construction.

2)Epoxy resin coating, radial CP wire.

3)Very small dissipation factor at high-frequency, very small inner temperature rise.

4) Good stability of capacitance, excellent insulation resistance property.

5) excellent self-healing property.

6) suitable for DC, pulse, high-frequency large-current application widely used in display, sound equipment, audio-visual devices, telecommunication equipment, data transmission and process facility and various electronic equipment.

Product picture

22uF 224nF Metallized Polyester Film Capacitors CL21 250V

Product shape

22uF 224nF Metallized Polyester Film Capacitors CL21 250V

Production

22uF 224nF Metallized Polyester Film Capacitors CL21 250V

Workshop& Equipment

22uF 224nF Metallized Polyester Film Capacitors CL21 250V

Packing method

22uF 224nF Metallized Polyester Film Capacitors CL21 250V

Certificate

22uF 224nF Metallized Polyester Film Capacitors CL21 250V

Exhibition

22uF 224nF Metallized Polyester Film Capacitors CL21 250V
