10UF 650V DC Link Film Capacitor KEMET R76 Air Conditioner Compressor AC Capacitors

Name: 10UF 650V DC Link Film Capacitor KEMET R76 Air Conditioner Compressor AC Capacitors
Brand: GDHY
Price: 1 USD

China 10UF 650V DC Link Film Capacitor KEMET R76 Air Conditioner Compressor AC Capacitors wholesale

Brand Name : GDHY

Model Number : C52 10UF 650V

Certification : SGS,ISO

Place of Origin : GUANGZHOU, CHINA

MOQ : 200PCS

Price : PLEASE CONTACT US FOR DETAILS

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : MORE THAN 1KPCS/MONTH

Delivery Time : 15 WORKING DAYS

Packaging Details : PLASTIC BAG

Brand : GDHY

Supplier Type : Original Manufacturer

Product Type : DC-LINK Capacitor

Model Code : C52651106JX08-01

Capacity : 10uF/106

Voltage : 650VDC

Operating Temperature : -40℃~+70℃ TMax105℃

Color : Black

Application : DC-link circuit for energy storage

Encapculation : Plastic shell

Contact Now

10uF 650V DC-LINK FILM CAPACITORS (SIMILAR AS KEMET R76 SERIES) AIR CONDITIONER FREQUENCY CONVERTER

Technical Parameter

Reference Standards	GB/T 17702 IEC 61071
Capacitance	10μF/106
Rated Voltage	650VDC
Capacity Tolerance	±5%(J);±10%(K)
Test voltage between electrodes	1.5Un(DC) 60S 25℃±5℃
Test voltage between electrodes and case	1000+2 X Un/√2 (VAC) 50Hz 60S (min 3000VAC)
Dissipation Factor	tgδ≤1.5X 10-3 ( at25℃±5℃, 100Hz)
Insulation Resistance	C•R≥5000S (at100VDC,at25℃±5℃,1Min)
Flame retardation	UL94V-0
Life Expectancy	100000h at UN and ≤70℃

Datasheet download: C52.pdf

Application

● Widely used in DC-Link Circuits for Energy Storage; Pulsed, DC-LINK filter capacitor

● Welding inverter DC filter capacitor; WBG Cinversion Systems (Power Supplies and Inverters), such as Inverter Power Supplies, Electric Vehicles, UPS, Frequency converters, Industrial and high-end power supplies, Welder Power Supplies, etc.

● Solar System Inverters and Micro-Inverters

Feature

● RoHS compliant with lead-free terminations

● Small size, Easy installation

● Polypropylene film dielectric

● Flame retardant epoxy resin coating, plastic shell, tinned copper wire

● High pulse current and high dv/dt; low ESL/ESR;

Product Picture
